IMB-152
Mini-ITX intel Baytrail-J1900/N2930 (0ºC – 60ºC)- Intel® Atom™ Baytrail-J1900/N2930 Processor
- IMB-152D (J1900) - Integrated Intel® Gen7 Intel® Graphics DX 11*, OGL3.2
- Supports Dual Channel DDR3L 1333MHz, 2 x SO-DIMM, up to 4GB system memory
- 1 x HDMI, 1 x D-Sub, 1 x Dual Channel 24-bit LVDS
- 4 xUSB 3.0, 6 x USB 2.0, 2 x SATA2
- 1 x mini-PCIe, 1 x PCIe x1 slot
- Gigabit LAN : 1 x Realtek Lan
- 1 x TPM Header
- 12 V DC-in
/
-
4G
-
5G
-
Display Port
-
HDMI
-
Intel
-
Interface
-
LAN
-
Serial
-
SSD
-
USB
Specifications
Processor system
|
CPU |
Intel® new AtomTM Baytrail-M/D Supports Hyper-Threading Technology Default J1900 Quad core processor |
|
Chipset |
(By CPU) |
|
BIOS/OS Support |
UEFI |
|
Watchdog |
0,1,2…255sec/min |
Expansion slot
|
PCI |
- |
|
Mini-PCIe |
1 (Half Size) |
|
mSATA |
- |
|
PCIe |
1 (x1) |
|
Cfast |
- |
|
M.2 |
- |
Memory
|
Technology |
Single Channel DDR3L 1333 MHz SDRAM |
|
Max. |
4GB |
|
Storage |
SATA2 (3.0Gb/s) |
Graphics
|
Controller |
Intel® Gen7 Intel Graphics DX 11*, OGL3.2 |
|
Max. Resolution |
1920 x 1200@60Hz |
Ethernet
Rear I/O
|
VGA |
1 |
|
HDMI |
1(Pin Header) |
|
DVI-I/D |
- |
|
Display Port |
- |
|
Ethernet |
1 Optional 2 |
|
USB |
4 x USB 3.0 |
|
Audio |
2 (Mic-in, Line-out) |
|
Serial |
3 x RS-232 |
Internal connector
|
USB |
6 ( 3*2.54 pitch header USB 2.0 compliant) |
|
LVDS/Inverter |
1/1 |
|
Serial |
3 (RS-232) |
|
SATA |
2 x SATA2 (3.0Gb/s) |
|
mSATA |
- |
|
Mini-PCIe |
1 |
|
GPIO |
4 x GPI + 4 x GPO Share with COM 5 |
|
SATA PWR |
1 |
|
SIM |
- |
Power requirement
|
Power Input |
12V DC-In (4-pin ATX PWR Con) |
Environment
|
Operating temp. |
0ºC – 60ºC |
|
Storage temp. |
- |
|
Humidity |
- |
Mechanical
|
Format factor |
Mini-ITX |
|
Dimensions |
6.7-in x 6.7-in |
|
Weight |
- |
|
Construction |
- |
