SINTRONES SBOX-2300
Intel Braswell N3060 (-30 ~ 60ºC, ambient w/ air)- Intel Braswell N3060 Atom CPU
- Triple Display Output (DVI-I / HDMI / VGA)
- Embedded OS (Win 10 and Ubuntu 14.04)
- Dual Gigabit Ethernet and 2 x RS-232
- Wide Range Operating Temp. : -30~60ºC
- Ultra Slim(40mm), Compact Size and Fanless
- DC 12V Power Input
/ IPC (Ordinador industrial)
-
DC
-
DVI
-
Sense ventilació
-
HDD
-
HDMI
-
Intel
-
Interfície
-
LAN
-
Linux
-
Serie
-
SSD
-
USB
-
VGA
-
Windows
Specifications
Processor system
|
CPU |
Intel N3710 Quad Core CPU up to 2.56GHz Intel N3160 Quad Core CPU up to 2.24GHz Intel N3060 Dual Core CPU up to 2.48GHz |
|
Chipset |
- |
|
BIOS/OS Support |
- |
|
Watchdog |
1 ~ 255 Level Reset |
Expansion slot
|
PCI |
- |
|
Mini-PCIe |
- |
|
mSATA |
- |
|
PCIe |
- |
|
Cfast |
- |
|
M.2 |
- |
Memory
|
Technology |
1 x DDR3L-1600 SO-DIMM |
|
Max. |
8GB |
|
Storage |
1 x 2.5” Drive Bay for SATA Type Hard Disk Drive / SSD 1 x SATA DOM |
Graphics
|
Controller |
Intel HD Graphics |
|
Max. Resolution |
- |
Ethernet
Rear I/O
|
VGA |
(Through DVI-I*) |
|
HDMI |
(Through DVI-I*) |
|
DVI-I/D |
HDMI/DVI/VGA(Through DVI-I*) |
|
Display Port |
Max 3 Display Outputs |
|
Ethernet |
2 |
|
USB |
2 x USB 2.0 and 2 x USB 3.0 Ports |
|
Audio |
Line-Out / Mic-in |
|
Serial |
2 x RS-232 Ports (2 x RS-232/422/485), Optional Max. 4 x RS-232 |
Internal connector
|
USB |
- |
|
LVDS/Inverter |
- |
|
Serial |
- |
|
SATA |
- |
|
mSATA |
- |
|
Mini-PCIe |
- |
|
GPIO |
- |
|
SATA PWR |
- |
|
SIM |
- |
Power requirement
|
Power Input |
DC 12V Input |
Environment
|
Operating temp. |
-30 ~ 60ºC, ambient w/ air |
|
Storage temp. |
-40 ~ 85ºC |
|
Humidity |
10 ~ 95% @ 40ºC (non-condensing) |
Mechanical
