SINTRONES VBOX-3200-M12
AMD G-T56N/G-T40E (-40 ~ 70°C(SSD), ambient w/ air)- AMD G-T56N Dual Core APU with Radeon HD 6320
- Wireless Support LTE, 3.5G, WLAN, GPS, GSM/GPRS, Bluetooth
- 2 x M12 LAN Ports
- 9V - 32V DC Power Input
- Smarter Vehicle Power Ignition for Variety Vehicle
- 4 x DI / 2 x DO with Relay 12V / 80mA
- 1 x CAN Bus 2.0B (Optional)
- EN50155, EN50121-3-2 certified for temperature ranges up to Class TX
- EN61373 certified for shock and vibration resistance
/ IPC(Computador industrial)
-
AMD
-
DC
-
DVI
-
GPS
-
Interface
-
LAN
-
Lte
-
Serial
-
SSD
-
USB
Specifications
| SYSTEM | |
|---|---|
| CPU | AMD G-T56N Dual Core 1.65GHz AMD G-T40E Dual Core 1.0GHZ (Optional) |
| Memory | 2 x DDR3 1333MHz SO-DIMM up to 8GB |
| Chipset | AMD A50M Controller Hub |
| LAN Chipset | 2 x Realtek RTL8111E Gb/s Ethernet Onboard, Support PXE and Wake On Lan |
| Audio | Realtek ALC662 HD Codec Onboard |
| Watchdog | 1 ~ 255 Level Reset |
| POWER REUQIREMENT | |
| Power Input | 9V -32V DC Power Input |
| Power Protection | Automatics Recovery Short Circuit Protection |
| Power Management | Vehicle Power Ignition for Variety Vehicle |
| PPower Off Control | Power off Delay Time Setting by Software, Default is 5 Mins |
| Backup Battery | Internal Battery Kit for 10 Mins Operating (Optional) Patent No. : M447854 - Build-in Battery |
| GRAPHICS | |
| Graphics | AMD G-T56N Radeon HD 6320 UVD3 Hardware Video Decoder - MPEG2, MPEG4, H.264, VC-1, WMV |
| Resolution | Up to 2560 x 1600 @ 85Hz |
Rear I/O
|
VGA |
1 x VGA Output (Share with DVI-I) |
|
HDMI |
- |
|
DVI-I/D |
1 x DVI-I |
|
Display Port |
- |
|
Ethernet |
2 |
|
USB |
4 x USB 2.0 Ports on Front I/O |
|
Audio |
1 x Line-out (Mic-in or Line-in Optional) |
|
Serial |
3 x RS-232 (2 with RS-422/485 (Auto Direction Control)) |
Internal connector
|
USB |
- |
|
LVDS/Inverter |
- |
|
Serial |
- |
|
SATA |
- |
|
mSATA |
- |
|
Mini-PCIe |
- |
|
GPIO |
- |
|
SATA PWR |
- |
|
SIM |
1 x SIM Card Socket Supported Onboard with eject |
Power requirement
|
Power Input |
9V - 32V DC Power Input |
Environment
|
Operating temp. |
-40 ~ 70ºC (SSD), ambient w/ air |
|
Storage temp. |
-40 ~ 80ºC |
|
Humidity |
10 ~ 95% (non-condensing) |
Mechanical
|
Format factor |
- |
|
Dimensions |
250 x 150 x 55 mm |
|
Weight |
1780 g (Barebone) |
|
Construction |
Aluminum Alloy |
