VBOX-3610

intel 5650U/5010U/4650U/4300U/4010U/2980U (-40 ~ 70°C (Default CPU 17Watt))

Intel Core i7-5650U / Core i3-5010U
Wireless support LTE, 3.5G w/ Dual SIM Cards, WLAN, GPS Dead Reckoning, GSM/GPRS, BT
IEC60945 Maritine Certified
9V~36V DC Power Input
Smarter Vehicle Power Ignition for Variety Vehicle
Support Dual Hot Swappable SATA Storage
Support 1 x CAN Bus 2.0B (Optional)

/ IPC(Computador industrial)

Specifications

Processor system

CPU	Intel Gen 5 Core i7-5650U 2.2GHz up to 3.1GHz Intel Gen 5 Core i3-5010U 2.1GHz Intel Gen 4 Core i7-4650U 1.7GHz up to 3.3GHz Intel Gen 4 Core i5-4300U 1.9GHz up to 2.9GHz Intel Gen 4 Core i3-4010U 1.7GHz Intel Gen 4 Dual Core Celeron 2980U 1.6GHz
Chipset	-
BIOS/OS Support	-
Watchdog	1 – 255 Step

Expansion slot

Memory

Technology

2 x DDR3L 1600 MHz SO-DIMM

Max.

16GB

Storage

2 x 2.5” Drive Bay for SATA Type HDD/SSD, Support RAID 0, 1

1 x SATA DOM

Graphics

Controller

Intel® HD Graphics 6000 / 5000

DirectX Video Acceleration (DXVA) for Accelerating Video

Processing - Full AVC/VC1/MPEG2 HW Decode

Supports DirectX 11/10.1/10/9 and OpenGL 4.0

Max. Resolution

4096 x 2304

Ethernet

Rear I/O

VGA	1
HDMI	-
DVI-I/D	1
Display Port	1
Ethernet	2
USB	2 x USB 3.0 Ports, 2 x USB 2.0 Ports
Audio	1 x Line-out and 1 x Mic-in (Line-in Optional)
Serial	4 x RS-232 (2 with RS-422/485 (Auto Direction Control))

Internal connector

USB	-
LVDS/Inverter	-
Serial	-
SATA	-
mSATA	-
Mini-PCIe	-
GPIO	-
SATA PWR	-
SIM	2 x SIM Card Sockets Supported Onboard with eject

Power requirement

Power Input

9V - 36V DC Power Input

Environment

Mechanical
